High Performance(3.5kg/cm) Robot Digital Servo

• Storage Temperature Range: -30 ~ 80 °C
• Operating Temperature Range: -15 ~ 70 °C
• Gear type: Metal Gear
• Limit angle: NO limit
• Bearing: NO Ball bearings
• Horn gear spline: 25T
• Horn Type: Plastic, POM
• Case: ABS
• Motor: Core motor
• Operating Voltage Range: 4.8 - 7.4 V
• No-load speed: 0.1 sec / 60 degree @ 6 V
• Running current (at no load): 170 mA @ 6 V
• Peak stall torque: 3.5kg.cm @ 6 V
• Rated torque: 1.15 kg.cm @ 6 V
• Stall current: 1200 mA @ 6 V
• Command signal: Pulse width modification
• Amplifier Type: Digital (comparator)
• Pulse width range: 500~2500 usec
• Stop position: 1500 μsec
• Running degree: 180° (when 600~2400 μ sec)
• Dead band width: 2μsec
• Rotating direction: CCW (when 1500~2400 μsec)
• Weight: 12.5 +- 1 g
